Nemesis OSCA-DXVF DMX Video Fader Unit
Building on the success of the proven Nemesis DMXVF video fader the new OSCA-DXVF adds OSC and other advanced features  whilst still maintaining all the old favourites.
The OSCA-DXVF is a Dual Channel DMX and OSC Controlled Video Fader designed to allow users to restrict light emission levels from monitor screens - particularly those mounted in an auditorium - when darkness is required during a production.
The OSCA-DXVF maintains video sync signal during a blackout avoiding ugly 'Signal Lost' messages which would otherwise be shown on modern LCD screens.
The exact brightness can be faded directly via OSC or DMX from 0 to 100% in 1% increments, effectively treating the video screen brightness like a conventional lighting fixture.
The OSCA-DXVF can form part of an extensive OSC network allowing lighting, sound, stage management and other departments to all control screen brightness if required.
With the addition of a OSCA-R5 button box different presets or states can be controlled at the push of a button allowing, for example, a musical director to dim certain screens as-and-when they wish.
​Under DMX control the OSCA-DXVF can directly interface with all modern lighting consoles.
Key Features:
Video:
- 2 Ă— Independent composite video channels
- In-built 4-output Video Distribution Amplifier per channel
- Fades input signal to black whilst retaining sync signal
- Zero video latency
Control:
- DMX mode mode
- OSC mode
- DMX with OSC fallback mode (OSC automatically takes over if DMX stream not detected)
- Manual mode
- Entirely separate channels - control one with DMX and the other with OSC
- Each channel controlled by the same or separate OSC or DMX messages
- DMX invert: video mixer (where max DMX Â = max video) Â or video blackout (where max DMX Â = video blackout)
- DMX thru
- Remote set up and control over ethernet
 General:
- 1U 19" rack mount
- Front Panel LED display showing current status
- 75Ω Video BNC In/Outs, 5-pin XLR DMX Connections with link-thru, industrial Ethercon network connector
- Fully compatible with all 3rd party OSC commands and Nemesis OSCA range
- Config download, backup and restore
- Internet enabled for updates and upgrades
- DHCP served or fixed IP address
- Industrial Ethercon network connector
- Multicolour LEDs showing network, DMX, action and power status
​​​Supplied in the box:
- OSCA-DXVF
- PowerCon to UK plug
